Model | CNP330A | ||
Engine Type | Honda GX390 | Chinese Petrol Engine | Chinese Diesel 186FA |
Power kw(hp) | 8.2(13.0) | 8.2(13.0) | 6.6(10.0) |
Net Weight kg(lbs) | 300(661) | 300(661) | 316(696) |
Frequency vpm | 4800 | ||
Centrifugal Force kN | 38 | ||
Compaction Depth mm(in) | 900(35.4) | ||
Travel Speed m/min(ft/min) | 21(68.9) | ||
Efficiency m2/hr(ft2/hr) | 844(9083) | ||
Plate Size mm(in) | 900*470(35.4*18.5) without extension plate 900*670(35.4*26.4) with extension plate | ||
Package mm | 995*500*1470 | ||
Model | CNP330A | ||
Engine Type | Honda GX390 | Chinese Petrol Engine | Chinese Diesel 186FA |
Power kw(hp) | 8.2(13.0) | 8.2(13.0) | 6.6(10.0) |
Net Weight kg(lbs) | 300(661) | 300(661) | 316(696) |
Frequency vpm | 4800 | ||
Centrifugal Force kN | 38 | ||
Compaction Depth mm(in) | 900(35.4) | ||
Travel Speed m/min(ft/min) | 21(68.9) | ||
Efficiency m2/hr(ft2/hr) | 844(9083) | ||
Plate Size mm(in) | 900*470(35.4*18.5) without extension plate 900*670(35.4*26.4) with extension plate | ||
Package mm | 995*500*1470 | ||
