Use the CN4820 as the power supply.
Model | CNP25E |
Net Weight kg(lbs) | 145(320) |
Frequency vpm | 3925 |
Centrifugal Force kN | 25 |
Compaction Depth mm(in) | 300(11.8) |
Travel Speed m/min(ft/min) | 15(49) |
Efficiency m2/hr | 432(4650) |
Plate Size mm | 628*400(24.7*15.7) |
Working Size mm | 1160*410*910 |
Package mm | 690*430*980 with wheel 750*430*980 without wheel |
Model Type | Permanent magnet DC motor |
Rated Performance kW | 2.2 |
Rated Current A | 58 |
Voltage V | 48 |
Speed rpm | 3400 |
