Model | CNYL642-Z-2A | ||
Engine Type | Honda GX390 | Chinese Petrol Engine | Chinese Diesel 186FE |
Power kW(hp) | 8.2(13.0) | 8.2(13.0) | 6.3(9.0) |
Net Weight kg(lbs) | 965(2127) | 965(2127) | 975(2150) |
Starting Mode | Electric | ||
Travel Speed m/hr | 0~6000 | ||
Drive Type | Hydraulic Drive | ||
Vibration Type | Mechanical | ||
| Steering Mode | Hydraulic Steering | ||
| Steering Angle | 28° | ||
| Vibration Drum(Front/Rear) | Front | ||
| Vibration Frequency Hz | 65 | ||
| Centrifugal Force kN | 20 | ||
| Water Tank Capacity L | 67 | ||
| Drum Size mm | Φ500*700*2 | ||
| Gradebility | 30° | ||
Package mm | 2000*880*1580 | ||
Model | CNYL642-Z-2A | ||
Engine Type | Honda GX390 | Chinese Petrol Engine | Chinese Diesel 186FE |
Power kW(hp) | 8.2(13.0) | 8.2(13.0) | 6.3(9.0) |
Net Weight kg(lbs) | 965(2127) | 965(2127) | 975(2150) |
Starting Mode | Electric | ||
Travel Speed m/hr | 0~6000 | ||
Drive Type | Hydraulic Drive | ||
Vibration Type | Mechanical | ||
| Steering Mode | Hydraulic Steering | ||
| Steering Angle | 28° | ||
| Vibration Drum(Front/Rear) | Front | ||
| Vibration Frequency Hz | 65 | ||
| Centrifugal Force kN | 20 | ||
| Water Tank Capacity L | 67 | ||
| Drum Size mm | Φ500*700*2 | ||
| Gradebility | 30° | ||
Package mm | 2000*880*1580 | ||
