Model | CNP90W | |
Engine Type | Honda GX160 | Chinese Petrol Engine |
Power Kw(hp) | 3.6(5.5) | 4.1(6.5) |
Net Weight kg(lbs) | 90(198) | 90(198) |
Frequency vpm | 5600 | |
Centrifugal Force kN | 15 | |
Compaction Depth mm(in) | 300(11.8) | |
Travel Speed mm/min(ft/min) | 23(75.5) | |
Eifficiency m²/hr(ft²/hr) | 690(7427) | |
Plate Size mm(in) | 580*500(22.8*19.7) | |
Water Tank Capacity L | 12 | |
Package mm | 690*525*605 | |
Model | CNP90W | |
Engine Type | Honda GX160 | Chinese Petrol Engine |
Power Kw(hp) | 3.6(5.5) | 4.1(6.5) |
Net Weight kg(lbs) | 90(198) | 90(198) |
Frequency vpm | 5600 | |
Centrifugal Force kN | 15 | |
Compaction Depth mm(in) | 300(11.8) | |
Travel Speed mm/min(ft/min) | 23(75.5) | |
Eifficiency m²/hr(ft²/hr) | 690(7427) | |
Plate Size mm(in) | 580*500(22.8*19.7) | |
Water Tank Capacity L | 12 | |
Package mm | 690*525*605 | |
